| Manufacturer Part Number | 1 986 S00 673 |
| Voltage [V] | 12 |
| Rated Power [kW] | 1,1 |
| Number of mounting bores | 1 |
| Number of threaded holes | 1 |
| Number of Teeth | 9 |
| Clamp | 30,50 |
| Flange Diameter [mm] | 74 |
| Pinion Rest Position [mm] | 15 |
| Thread Size | M10x1,25 |
| Bore Diameter [mm] | 11 |
| Length [mm] | 203 |
| Position/Degree | rechts |
| Mounting Angle [degrees] | 35 |
| Jaw opening angle measurement [Degree] | 35 |
| Mounting bore angle measurement [Degree] | 35 |
| Brand | Reference |
|---|---|
| TOYOTA | 281000N010 |
| Brand | Reference |
|---|---|
| LUCAS ELECTRICAL | LRS02333 |
| LUCAS ELECTRICAL | LRS2333 |
| BOSCH | 0 001 107 440 |
| BOSCH | 0 001 107 441 |
| BOSCH | 0 986 021 560 |
| HC-PARTS | CS1453 |
| Make | Model | Vehicle | Year From | Year To | Capacity(CC) |
|---|---|---|---|---|---|
| TOYOTA | YARIS (_P9_) | 1.4 D-4D (NLP90_, NLP90R) | 2005-08 | 2012-12 | 1364 |
| TOYOTA | AURIS (_E15_) | 1.4 D-4D (NDE150_, NDE150R) | 2007-03 | 2012-09 | 1364 |
| TOYOTA | AURIS Hatchback Van (_E15_) | 1.4 D-4D (NDE150) | 2007-03 | 2012-09 | 1364 |
| Brand | BOSCH |
|---|---|
| MPN | 1 986 S00 673 |
| Manufacturer Part Number | 1 986 S00 673 |
| Manufacturer | BOSCH |
| Type | Starter |
| Function | Starter |
| Reference OE/OEM Number | TOYOTA 281000N010 LUCAS ELECTRICAL LRS02333 LRS2333 BOSCH 0, 001 107 440 0 001 107 441 0 986 021 560 HC-PARTS CS1453 |
| Voltage [V] | 12 |
| Rated Power [kW] | 1,1 |
| Number Of Mounting Bores | 1 |
| Number Of Threaded Holes | 1 |
| Number Of Teeth | 9 |
| Clamp | 30,50 |
|---|---|
| Flange Diameter [mm] | 74 |
| Pinion Rest Position [mm] | 15 |
| Thread Size | M10x1,25 |
| Bore Diameter [mm] | 11 |
| Length [mm] | 203 |
| Position/Degree | rechts |
| Mounting Angle [degrees] | 35 |
| Jaw Opening Angle Measurement [Degree] | 35 |
| Mounting Bore Angle Measurement [Degree] | 35 |
| EAN | 4047026541601 |
